What is a Cylindrical Lens?

A cylindrical mirror has curvature in one dimension and is used to focus a light source into a one-dimensional shape. In other words, changing the way the light source in an optical system and converting it to a linear light source. Cylindrical lenses can be used to correct the dispersion of an optical system. It is widely used in high-precision measuring instruments and equipment such as high-power, long-range linear interferometers. Cylindrical mirror lenses are also commonly used in synchrotron radiation beamlines, barcode scanning and high power laser systems.

Classification

Plano-convex Cylindrical Lens, Plano-concave Cylindrical Lens, Bi-convex Cylindrical Lens, Bi-concave Cylindrical, Curved Moon Cylindrical Lens, Column Intersecting Cylindrical Lens and Shaped Class Cylindrical Lens. It has one-dimensional magnification function.

Cylindrical Mirror Manufacturing

Including rough grinding, fine grinding, polishing, centering and edge grinding.

Materials

Colorless optical glass, laser crystals, fused silica, radiation-resistant glass, ultraviolet and infrared materials, metallic materials such as SiO₂, CaF₂, BaF₂, ZnSe, ZnS, etc.
